Draft

At Brilly Engineering, we view drafting as an art form. It is a way of storytelling in a practical and technical context. A well prepared drawing must clearly communicate the intent, processes, methods and details that guide a project from one stage to the next. It should speak to every person the drawing relates to across the full lifecycle of a product or structure.

We believe a technical drawing must have purpose and function. It should be clear, accessible and relevant to the people using it. Because we model using a chronological and hierarchical approach, our drawing structures naturally reflect job roles, responsibilities, workflows and levels of organisation that are often lost in the complexity of a large project.

Take something as simple as a welded frame. Throughout its life, this product may go through several states, each involving different people or operations. It might begin with ordering raw material, move to cutting on a bandsaw, include laser cutting of plate components, progress through welding, machining and painting, and finally be assembled or lifted into place. Each of these steps informs the way we draft, and each has its own purpose and audience.

Unfortunately, due to confidentiality and our respect for the valuable work of our clients, we are limited in what we can share publicly. Below is a selection of sample drawings we are able to show. Please contact us for more information.
